Main Parameter
| Model Number | 500 | 630 | |
Dia. Of Single Wire(mm) | Copper | 1.5-5.0 | |
Aluminum | 1.8-5.0 | ||
Max.Section Square(mm2) | Cu | 500 | |
Al | 630 | ||
Max Linear Speed(m/min) | 7.32-55.29 | 7.62-57.93 | |
Pay-off In Cage | PND500 | ||
Stranding Pitch(mm) | 45-1105 | 56-1259 | |
Take-up Bobbins(mm) | PN1600-PN2500 | ||
Capstan(mm) | 2000mm | ||
Features
1.All Cages, Pre-Spiraling Heads, Taping Head, Capstan & Takeup are separately driven.
2.All bobbins can be loaded/unloaded simultaneously by automatic loading equipment, thereby reducing loading/unloading time to Max. 30 minutes.
3.Lay is fed in MMI (Operator touch screen) instead of Gearbox. Any lay value in the range can be set & achieved that ensure easy operation.
4.In Power failure situation, the machine comes to a controlled stop by emergency braking system, enabling the bobbin is held by spring pressure with a secondary positive lock. The release of bobbin is by externally plugged pneumatic compressed Air.
5.Constant Bobbin back tension achieved by Electronic pneumatic valve & Single bobbin rotation is electronically sensed for maintaining consistent tension by positive motor control system or passive mechanical equipment.
6.Multiple bobbin size available(400,500,630.etc)
7.Mutiple host with mutiple cage number((6.12.18.24.30)) optional
BEYDE is a subsidiary of Hebei HEXING electrical machinery Co., Ltd., a professional manufacturer and exporter of cable equipment. Founded in 1983 by Mr. Chen Yuke, grandfather of current president Mr. Chen Jiuzhang, HEXING has a well-equipped factory with an area of 10,000 square meters located in Hejian, Hebei province, home to the manufacture of cable machinery and equipment. HEXING is a well-known brand in China's cable industry, serving over 70% cable manufacturers in northern China. BEYDE supplies all types of machines including Laying-up machine, Rigid Stranding Machine, Tubular Stranding Machine, Planetary Stranding Machine and help wire & cable manufacturers lower production cost and ensure quality of final products. Beyde was established for export business of HEXING as a result of increasing OEM business of HEXING for many Chinese exporters. With mature technological expertise, BEYDE provides cost-effective solutions for wire & cable manufacturers to expand or update their production lines. Our machines have been exported to the United States, Russia, Malaysia, Saudi Arabia, Iran and other countries. The quality and performance of our products has been widely recognized and praised by overseas customers. We can customize the capacity, color of our machines according to the demands of clients. We look forward to working with more overseas cable manufacturers to have mutually beneficial cooperation and create success and glory together!
Our products passed ISO 9001 international quality system certification with domestic first-class product quality testing center.
FAQ |
1,Q: What is your main brand for the electrical and mechanical parts? A: China famous brand |
2, Q:could we appoint the parts brand? A: Yes, ABB, SIEMENS, Danfoss, or theirs that you like. |
3, Q: could you please arrange the installation and commissioning ? A: Yes , we could and the buyer pay the charge |
4, Q: could you arrange the production education? A: Yes , we could and the buyer pay the charge |
5, Q: could you do the design for the whole plant A: Yes , we can. |
6, Q: could you offer the production process design A: Yes , we can. |
7, Q: what is the difference with other supplier? A: what we could offer to other customer is not only the machine itself, also we could offer: factory design, production process design , QC control and education and assist machine and raw material offering . |
8.Q:What's the payment terms? A:T/T,30% deposit and 70% balance before delivery. |
9, Q:How long the guarantee: A: one year and charge for repair the whole life. |
