Features:
Technical Specification:
Machine model | HT-500P | HT-630P | HT-800P | HT-1000P | HT-1250P |
Sectional area twisted(mm2) | 0.50-2.50 | 0.75-6.00 | 2.50-16.0 | 6.0-25.0 | 10.0-50.0 |
Inlet wire dia. | 0.08-0.45 | 0.25-1.00 | 0.30-1.60 | 0.40-1.80 | 0.60-2.50 |
Twisting pitch | 4.22-39.64mm | 11.15-100mm | 17-200mm | 35-200mm | 35-300mm |
Main motor power | AC7.5KW | AC11KW | AC18.5KW | AC22KW | AC37KW |
Max. rotating speed | 2200RPM | 1800RPM | 1200RPM | 1000RPM | 800RPM |
Tension control | Magnetic powder clutch automatic adjustment | ||||
Traverse type | Polished rod traverse, wire lay is adjustable | ||||
Wire break sensor | Digital display, machine auto-stop if wire break | ||||
Rotating direction | S.Z Direction | ||||
Spooling bobbin | 500mm | 630mm | 800mm | 1000mm | 1250mm |
------------------------------------------
HT-630P Bunching machine:
Our factory show:
CE for multi wire drawing machine:
Exhibition is shanghai city:
Commissioning wire drawing machine in Turkey :
Our customers come from different countries around the world.
Multi wire drawing machine with annealer(4/8/10/16/24wires) | 8mm Rod breakdown wire drawing machine with annealer(1/2wires) | 9.5mm Aluminum Rod breakdown wire drawing machine with online annealer | Electrolytic Tin-plating Machine(3000Sn/6000Sn/10000Sn) |
Multi wire draiwng machine with annealer(4/8/10/16/24) | All kind of double twisting buching machine | Extrusion machine | Stell bobbin |
